VT-42 R2408-L3HY-4*10G

OVERVIEW

The VT-42 R2408-L3HY-4*10G is a 10G uplink L3 managed, Supports Ring Network Functions and Common Industrial Standard independently developed by . It has 24* 100/ 1000Base-X SFP ports and 8*10/ 100/1000Base-T RJ45 combo ports and 4* 1/ 10G SFP+ fiber slot ports. Each port can support wire-speed forwarding.

The VT-42 R2408-L3HY-4*10G has L3 network management function, supports IPV4/IPV6 management, dynamic routing full line-speed forwarding, complete security protection mechanism, perfect ACL/QoS policy, and rich VLAN functions, easy to manage and maintain. With industry-leading ring network technology. It supports a variety of industrial-grade redundant ring network protocols, and each port can form a ring network, supporting chain ring network, starring network, double starring network, ring network, tangent network ring network, intersecting ring network, coupled ring network, self-healing within ERPS <20ms of the ring network. The switches series has high reliability, high security, and high manageability, ensures reliable transmission of key data, supports remote management. The product completely follows the industrial product design and materials. The shell is made of aluminium alloy material to enhance heat dissipation. It has excellent adaptability to the industrial site environment (including mechanical stability, climate environment adaptability, electromagnetic environment adaptability , etc.). Protection level reaches IP40 and supports AC+DC dual redundant power supply. It is suitable for intelligent transportation, rail transit, power industry, mining, petroleum, and industrial scenes such as shipping, metallurgy, and green energy construction form a cost-effective, stable, and reliable communication network.

FEATURE

Gigabit access, 10G uplink

◇ Support non-blocking wire-speed forwarding.

◇ Support full-duplex based on IEEE802.3x and half-duplex based on Backpressure.

◇ Supports Gigabit Ethernet port and 10G SFP+ uplink port combination, which enables users to flexibly build networking to meet the needs of various scenarios

Security

◇ Support port isolation.

◇ Support port broadcast storm suppression.

◇ Support IP+MAC+port+VLAN quadruple flexible combination binding function.

◇ Support 802. 1X authentication to provide authentication functions for LAN computers, and control the authorization status of controlled ports according to the authentication results

Strong business processing capability

◇ Support ERPS ring network and STP/RSTP/MSTP to eliminate layer 2 loops and realize link backup.

◇ Support IEEE802. 1Q VLAN, Users can flexibly divide VLAN, Voice VLAN, and QinQ configuration according to their needs.

◇ Support static and dynamic aggregation to effectively increase link bandwidth, realize

Load balancing, link backup and improve link reliability

◇ Support QoS, port-based, 802. 1P-based and DSCP-based three priority modes and four queue scheduling algorithms: Equ, SP, WRR, and SP+WRR.

◇ Support ACL to filter data packets by configuring matching rule processing operations and time permissions, and provide flexible security access control policies.

◇ Support IGMP V1/V2/V3 multicast protocol, IGMP Snooping meets multi-terminal high-definition video surveillance and video conference access requirements

Stable and reliable

◇ CCC, CE, FCC, RoHS.

◇ Low power consumption, No fan, aluminum shell.

◇ The user-friendly panel can show the device status through the LED indicator of PWR, Link.

◇ Self-developed power supply, high redundancy design, providing a long term and stable power output.

Easy operation and maintenance management

◇ Support CPU monitoring, memory monitoring, Ping detection, cable length detection.

◇ Support HTTPS, SSLV3, SSHV1/V2 and other encryption methods, making management more secure. ◇ Support RMON, system log, and port traffic statistics to facilitate network optimization and transformation.

◇ Support LLDP to facilitate the network management system to query and judge the communication status of the link.

◇ Support Web network management, CLI command line (Console, Telnet), SNMP (V1/V2/V3) and other diversified management and maintenance.
